W640D
- Part number
- W640D
- Pitch (DP)
- 6
- Number of teeth (z)
- 40
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
Seris - W640D
Part number :
W640D
Pitch (DP) :
6
Number of teeth (z) :
40
Pressure angle :
14 1/2 °
Weight :
7.60 lbs
Pitch diameter :
6.667 inch
Bore :
1 1/4 inch
Gear tooth width (b) :
1 inch
Hub diameter (H) :
2 3/4 inch
Hub protract (P) :
1 inch
