WG10

Part number: WG10

Pitch (DP): 10

Weight: 0.32 lbs

We will provide you with the most suitable solution.

WG10

Image may differ from product. See technical specification for details.

Part number : WG10

Pitch (DP) : 10

Weight : 0.32 lbs

Pressure angle : 14 1/2 °

Gear tooth width (b) : 1 3/8 inch

Helix angle : 4° 34'

Pitch diameter : 1.250 inch

Bore : 5/8 inch

Keyway : 3/16 × 3/32 inch

WG10
