Asymmetrical Spherical Roller 35.5x60.149 mm
- Nominal diameter (Dw)
- 35.5 mm
- Length (Lw)
- 60.149 mm
- Mass
- 0.418 kg
We will provide you with the most suitable solution.
Image may differ from product. See technical specification for details.
Specifications
구형 롤러 Seris - Asymmetrical Spherical Roller 35.5x60.149 mm
Nominal diameter (Dw) :
35.5 mm
Length (Lw) :
60.149 mm
Mass :
0.418 kg
Type :
Asymmetrical
R :
169 mm
Material :
52100
Hardness :
60 HRC
Heat treatment :
Hardened
Material composition aluminum :
0-0.050%
Material composition carbon :
0.93-1.10%
Material composition chromium :
1.30-1.60%
Material composition copper :
0-0.30%
Material composition manganese :
0.25-0.45%
Material composition molybdenum :
0-0.10%
Material composition nickel :
0-0.25%
Material composition oxygen :
0-0.0015%
Material composition phosphorus :
0.025%Max
Material composition silicon :
0.15-0.35%
Material composition sulfur :
0.025%Max
Material composition iron :
Remainder
Rohs :
Compliant
Reach :
Compliant
Description
Features & Benefits
구형 롤러는 구형 롤링 표면을 가지고 있습니다. 이러한 롤러가 있는 베어링은 자체 정렬 특성을 가지고 있으며 큰 하중을 견딜 수 있습니다.
